SCARAB X5
4,000 lbs
SCARAB X5
The Scarab X5 redefines what is possible in confined-space heavy transport. 4,000 lbs payload through a 1,000mm corridor. 50% more than the nearest competitor. 45° max gradient, 280Ah full-shift battery, full-display proportional remote with real-time gradient and load monitoring. Platform rotation standard. Built in the USA.
Track Color
Full Specifications
| Maximum Payload | 4,000kg | |
| Track Width | 1000mm | |
| Machine Weight | 970kg | |
| Battery Capacity | 280Ah | |
| Max Travel Speed | 2km/h | |
| Deck Height (lowered) | 245mm | |
| Max Gradient | 45° | |
| Wireless Remote | Full Proportional Display |
In Action
Video Coming Soon
Accessories & Options
Select accessories to add to your quote request.
Extended Range Remote
100m wireless range
Extended wireless remote with 100m operating range. Full proportional control with display feedback. Ideal for long-run corridor moves and multi-operator sites.
Low-Profile Deck Insert
Reduces deck height by 65mm
Drop-in deck insert reduces overall machine height by 65mm for moves in environments with extremely tight vertical clearance.
Side Guide Rail Kit
Adjustable load containment rails
Bolt-on adjustable side guide rails for secure load containment on loose or irregular loads. Adjustable from 200–900mm. Removes without tools.
Hydraulic Loading Ramps
Self-levelling approach ramps
Hydraulic self-levelling approach ramps for loading the carrier onto truck beds and loading docks. Rated to full machine payload. Includes storage brackets.
Platform Rotation Motor
360° powered platform rotation
360° powered platform rotation controlled from the main remote. Allows precise load positioning without secondary lifting equipment. Included standard on Scarab X5.
48V Auxiliary Power Kit
Powers external tools from the machine
48V auxiliary power output kit. Powers external tools, hoists, and powered attachments directly from the Scarab X5 battery system. Includes 5m cable and connector set.
